又到疯狂抢票的季节了，用python写一个简单的12306抢票软件
引言
每逢过年就到了12306抢票高峰期，自己总想研究一下12306购票的流程，虽然网上已经很多资料，但是总比不过自己的亲身体会，于是便琢磨着写一个抢票软件，本人比较熟悉python，所以软件是用python写的。
使用工具和库
开发环境是python3.6.2
开发工具是pycharm
辅助工具fiddler（神器）
使用到的重要库：
界面（tkinter）
http请求（requests库）
打包（pyinstaller库）
思考过程
其实本人职业并不是开发人员，任职是测试，但是喜欢平时用python写点小东西，所以开发大大们莫见笑。不废话，说说我才开始做的思考过程。
1.首先代码需要涉及前端和后台两个部分，前端我查了PyQt和Tkinter，觉得我这小东西没必要用PyQt，画个简单的前端即可，所以选择使用Tkinter
2.后台代码就是模拟12306订票流程，所以选择requests库做http请求
3.12306订票流程怎么去分解？fiddler神器帮了大忙，我就去12306官网正常登录购票，把整个流程的包全部抓到，然后分析请求数据和返回数据，后台代码就比较容易写了
4.根据后台代码的逻辑和返回，编写前端的用户提示和跳转
模拟12306购票流程
第一步登录：
在你登录12306网站的时候，网页会get一个验证码图片，这个步骤封装方法如下：
def get_img(self):
url="https://kyfw.12306.cn/passport/captcha/captcha-image?login_site=E&module=login&rand=sjrand&{}".format(random.random())
response=self.session.get(url=url,headers=self.headers,cookies=Func12306.cookies, verify=False)
path = os.path.abspath(..)
with open(path+"\\img.jpg",wb) as f:
f.write(response.content)
值得注意的是在抓包的时候发现请求里有个随机数，这里get请求需要带上这个随机数，所以使用了
random()
headers可以在初始化的时候写好
self.headers = {
Accept-Encoding: gzip, deflate, br,
Accept-Language: zh-CN,zh;q=0.8,
X-Requested-With: XMLHttpRequest,
Origin: https://kyfw.12306.cn,
User-Agent: Mozilla/5.0 (Windows NT 10.0; WOW64) AppleWebKit/537.36 (KHTML, like Gecko) Chrome/53.0.2785.104 Safari/537.36 Core/1.53.4355.400 QQBrowser/9.7.12672.400,
Content-Type: application/x-www-form-urlencoded; charset=UTF-8,
Accept: application/json, text/javascript, */*; q=0.01,
}
cookies会在你登录的时候自动保存在session里面 验证码图片可以保存在本地文件夹，然后给前端调用
根据fiddler抓到包的顺序来看，12306是先验证验证码，再验证帐号和密码，所以我们第一步是发送验证码信息给12306
验证码是由8个图片组成，12306服务器是校验的用户点击坐标来识别的，这里我们直接固定给出每个图片的中心坐标，简化了验证逻辑
def verify(self, clickList):
url = https://kyfw.12306.cn/passport/captcha/captcha-check
code = [35,35, 105,35, 175,35, 245,35, 35,105, 105,105, 175,105, 245,105]
verifyList = []
for a in clickList:
verifyList.append(code[int(a)])
codeList = ,.join(verifyList)
data = {
answer: codeList,
login_site: E,
rand: sjrand,
_json_att:"",
}
response = self.session.post(url=url, data=data, headers=self.headers, cookies=Func12306.cookies,verify=False)
try:
dic = loads(response.content)
except:
return "NetWorkError"
resultCode = dic[result_code]
resultMsg = dic[result_message]
self.verifyInfo = resultMsg
if str(resultCode) == "4":
return "verifySuccessful"
else:
return False
这是封装好的验证码验证逻辑
接下来就是要验证帐号和密码，根据fiddler抓包来看，验证一共发了三个请求，获得了一些需要后续验证在线的key，下面给出代码
def login(self, account, password):
url = https://kyfw.12306.cn/passport/web/login
data = {
username: account,
password: password,
appid: otn,
_json_att: "",
}
response = self.session.post(url=url, data=data, headers=self.headers, cookies=Func12306.cookies,verify=False)
try:
dic = loads(response.content)
except:
return "NetWorkError"
resultCode = dic[result_code]
resultMsg = dic[result_message]
self.loginInfo = resultMsg
if resultCode == 0:
print(登陆成功)
else:
return "loginFail"
if uamtk in dic.keys():
Func12306.uamtk = dic[uamtk]
url2 = https://kyfw.12306.cn/passport/web/auth/uamtk
data2 = {
"appid": "otn",
_json_att:""
}
Func12306.cookies[uamtk] = Func12306.uamtk
response2 = self.session.post(url=url2, data=data2, headers=self.headers, cookies=Func12306.cookies,verify=False)
try:
dic2 = loads(response2.content)
except:
return "NetWorkError"
resultCode2 = dic[result_code]
resultMsg2 = dic[result_message]
self.loginInfo = resultMsg2
if resultCode2 == 0:
print(验证通过)
else:
return "authFail"
if newapptk in dic2.keys():
Func12306.tk = dic2["newapptk"]
Func12306.cookies.pop(uamtk)
Func12306.cookies[tk] = Func12306.tk
url3 = https://kyfw.12306.cn/otn/uamauthclient
data3 = {"tk": Func12306.tk,
_json_att: "",
}
response3 = self.session.post(url=url3, data=data3, headers=self.headers, cookies=Func12306.cookies,verify=False)
try:
dic3 = loads(response3.content)
except:
return "NetWorkError"
resultCode3 = dic3[result_code]
resultMsg3 = dic3[result_message]
self.loginInfo = resultMsg3
if resultCode3 == 0:
return "LoginSuccessful"
else:
return False
登录成功后，我们需要前端跳转到我们自己设计的抢票UI上，UI的设计比较简陋，我给个图
查询用户联系人信息
这里和12306逻辑不一样的是，我们是抢票软件，联系是提前选择好的，而12306是在购票的时候填写的，所以我们要先提前获取到联系人然后插入到我们的前端里面，下面给出联系人的获取
def get_passenger_info(self):
url = https://kyfw.12306.cn/otn/confirmPassenger/getPassengerDTOs
data = {
"_json_att": "",
"REPEAT_SUBMIT_TOKEN": Func12306.reSubmitTk
}
response = self.session.post(url=url, data=data, headers=self.headers, cookies=Func12306.cookies,verify=False)
try:
dic = loads(response.content)
except:
return "NetWorkError"
if dic[messages] != []:
if dic[messages][0] == 系统忙，请稍后重试:
return systembusy
Func12306.passengerAllInfoList = dic[data][normal_passengers]
for a in Func12306.passengerAllInfoList:
Func12306.passengerNameList.append(a[passenger_name])
Func12306.passengerIdList.append(a[passenger_id_no])
Func12306.passengerPhoneList.append(a[mobile_no])
return Func12306.passengerNameList
查询车次
联系人获取完毕，座位类型是自己研究12306后固定写上去的
这个时候下一步就是查询车次
这里给出代码
def search_ticket(self, startStation, endStation, startDate):
try:
Func12306.cookies[_jc_save_fromDate] = startDate
Func12306.cookies[_jc_save_fromStation] = (parse.quote(startStation.encode(unicode_escape).decode(latin-1) + , + self.stationCodeDict[startStation]).replace(\\,%)).upper().replace(%5CU, %u)
Func12306.cookies[_jc_save_toDate] = startDate
Func12306.cookies[_jc_save_toStation] = (parse.quote(endStation.encode(unicode_escape).decode(latin-1) + , + self.stationCodeDict[endStation]).replace(\\,%)).upper().replace(%5CU, %u)
Func12306.cookies[_jc_save_wfdc_flag] = "dc"
except:
return "wrongtype"
try:
url1 = https://kyfw.12306.cn/otn/leftTicket/log?leftTicketDTO.train_date={}&leftTicketDTO.from_station={}&leftTicketDTO.to_station={}&purpose_codes=ADULT.format(startDate, self.stationCodeDict[startStation], self.stationCodeDict[endStation])
except:
return "wrongtype"
response1 = self.session.get(url=url1, headers=self.headers, cookies=Func12306.cookies, verify=False)
try:
dic1 = loads(response1.content)
except:
return "NetWorkError"
if dic1[status]:
print("OK")
else:
return "searchFail"
try:
url2 = https://kyfw.12306.cn/otn/{}?leftTicketDTO.train_date={}&leftTicketDTO.from_station={}&leftTicketDTO.to_station={}&purpose_codes=ADULT.format(Func12306.query, startDate, self.stationCodeDict[startStation], self.stationCodeDict[endStation])
except:
return "wrongtype"
response2 = self.session.get(url=url2, headers=self.headers, cookies=Func12306.cookies, verify=False)
try:
dic2 = loads(response2.content)
except:
return "NetWorkError"
if dic2 == "":
return "NetWorkError"
if dic2[status] is False:
if c_url in dic2.keys():
Func12306.query = dic2[c_url]
return "statusError"
return "statusError"
elif dic2["messages"] != []:
if dic["messages"][0] == u"选择的查询日期不在预售日期范围内":
return "search_error002"
else:
print("查询车成功")
Func12306.trainInfoStartTimeList, Func12306.trainInfoEndTimeList, Func12306.trainInfoSecretStrList, Func12306.trainInfoNameList, Func12306.trainInfoLocationList, Func12306.trainInfoNoList = [], [], [], [], [], []
Func12306.dw, Func12306.swz, Func12306.ydz, Func12306.edz, Func12306.yz, Func12306.yw, Func12306.wz, Func12306.rw, Func12306.gjrw, Func12306.tdz, Func12306.rz = [], [], [], [], [], [], [], [], [], [], []
Func12306.seatTypeList = (Func12306.edz, Func12306.ydz, Func12306.yz, Func12306.rz, Func12306.yw, Func12306.rw, Func12306.dw, Func12306.wz, Func12306.swz, Func12306.tdz, Func12306.gjrw)
for a in dic2[data][result]:
Func12306.trainInfoSecretStrList.append(a.split("|")[0])
Func12306.trainInfoNoList.append(a.split("|")[2])
Func12306.trainInfoNameList.append(a.split("|")[3])
Func12306.trainInfoStartTimeList.append(a.split("|")[8])
Func12306.trainInfoEndTimeList.append(a.split("|")[9])
Func12306.trainInfoLocationList.append(a.split("|")[15])
Func12306.dw.append(a.split("|")[33])
Func12306.swz.append(a.split("|")[32])
Func12306.ydz.append(a.split("|")[31])
Func12306.edz.append(a.split("|")[30])
Func12306.yz.append(a.split("|")[29])
Func12306.yw.append(a.split("|")[28])
Func12306.wz.append(a.split("|")[26])
Func12306.tdz.append(a.split("|")[25])
Func12306.rz.append(a.split("|")[24])
Func12306.rw.append(a.split("|")[23])
Func12306.gjrw.append(a.split("|")[21])
Func12306.seatTypeList = (
Func12306.edz, Func12306.ydz, Func12306.yz, Func12306.rz, Func12306.yw, Func12306.rw, Func12306.dw,
Func12306.wz, Func12306.swz, Func12306.tdz, Func12306.gjrw)
return Func12306.trainInfoNameList
这里值得注意的是查询出来的结果是用|分隔的很多信息，需要自己研究每个位置是什么信息，可以对照12306页面研究，然后把获取的信息返回给前端调用
还有重要一点要注意就是12306的url不是固定的，它会带一个随机的大字字母在url里，我们可以先随便写一个，然后从返回值里获取到这个大写字母
抢票逻辑
这个时候我们就可以让用户选择车次和联系人以及座位类型，然后就可以进入抢票逻辑
抢票需要发送很多请求
首先我们要知道我们要买的票到底有还是没有
def check_ticket(self, startStation, endStation, startDate, seatType, passengersList, trainName):
searchResult = self.search_ticket(startStation, endStation, startDate)
print(searchResult)
print(Func12306.edz)
if searchResult == "wrongtype":
return "wrongtype"
if searchResult == "NetWorkError":
return "NetWorkError"
if searchResult == "searchFail":
return "searchFail"
if searchResult == "statusError":
return "statusError"
if searchResult == "search_error002":
return "search_error002"
for a in trainName:
try:
trainIndex = Func12306.trainInfoNameList.index(a)
except:
return "listNeedRefresh"
for b in seatType:
print(trainIndex)
print(b)
print(Func12306.seatTypeList)
print(Func12306.seatTypeList[b])
if Func12306.trainInfoSecretStrList[trainIndex] == null:
print(没票了)
break
elif Func12306.seatTypeList[b][trainIndex] == u"无" or Func12306.seatTypeList[b][trainIndex] == "" :
print("没票了")
continue
elif Func12306.seatTypeList[b][trainIndex] == "*":
print("还没开始售票")
continue
elif Func12306.seatTypeList[b][trainIndex] != u"有" and len(passengersList) > int(Func12306.seatTypeList[b][trainIndex]):
print("票没人多")
continue
else:
print("查询到有票")
Func12306.trainIndexOfBuy = trainIndex
Func12306.seatIndexOfBuy = b
return Func12306.seatTypeList[b][trainIndex]
这里面还涉及多人购买的时候，票不够人多的情况，我这边处理是没足够的票，大家就都不买，要买一起买 。如果票足够了，我们就开始进入购票环节
首先需要验证用户信息
def check_user(self):
url = https://kyfw.12306.cn/otn/login/checkUser
data = {"_json_att": ""}
self.headers["Cache-Control"] = "no-cache"
self.headers["If-Modified-Since"] = "0"
response = self.session.post(url=url, data=data, headers=self.headers, cookies=Func12306.cookies,verify=False)
try:
dic = loads(response.content)
except:
return "NetWorkError"
if dic[data][flag]:
print("用户在线验证成功")
return True
else:
print(检查到用户不在线，请重新登陆)
return False
验证完之后需要开始提交订单
def submit_order(self, startStation, endStation, startDate):
url = https://kyfw.12306.cn/otn/leftTicket/submitOrderRequest
data = {"secretStr": parse.unquote(Func12306.trainInfoSecretStrList[Func12306.trainIndexOfBuy]),
"train_date": startDate,
"back_train_date": startDate,
"tour_flag": "dc",
"purpose_codes": "ADULT",
"query_from_station_name": startStation,
"query_to_station_name": endStation,
"undefined": ""
}
response=self.session.post(url=url, data=data, headers=self.headers,cookies=Func12306.cookies, verify=False)
try:
dic = loads(response.content)
except:
return "NetWorkError"
if dic[status]:
print(提交订单成功)
return True
elif dic[messages] != []:
if dic[messages][0] == "车票信息已过期，请重新查询最新车票信息":
print(车票信息已过期，请重新查询最新车票信息)
return "ticketInfoOutData"
else:
print("提交失败")
return False
提交完然后开始确认联系人信息
def confirm_passenger(self):
url = https://kyfw.12306.cn/otn/confirmPassenger/initDc
data = {"_json_att": }
response=self.session.post(url=url,data=data,headers=self.headers, cookies=Func12306.cookies,verify=False)
try:
Func12306.reSubmitTk = re.findall(uglobalRepeatSubmitToken = \(\S+?)\,response.text)[0]
Func12306.keyIsChange = re.findall(ukey_check_isChange\:\(\S+?)\,response.text)[0]
Func12306.leftTicketStr = re.findall(uleftTicketStr\:\(\S+?)\,response.text)[0]
except:
print("获取KEY失败")
return NetWorkError
def get_passenger_info(self):
url = https://kyfw.12306.cn/otn/confirmPassenger/getPassengerDTOs
data = {
"_json_att": "",
"REPEAT_SUBMIT_TOKEN": Func12306.reSubmitTk
}
response = self.session.post(url=url, data=data, headers=self.headers, cookies=Func12306.cookies,verify=False)
try:
dic = loads(response.content)
except:
return "NetWorkError"
if dic[messages] != []:
if dic[messages][0] == 系统忙，请稍后重试:
return systembusy
Func12306.passengerAllInfoList = dic[data][normal_passengers]
for a in Func12306.passengerAllInfoList:
Func12306.passengerNameList.append(a[passenger_name])
Func12306.passengerIdList.append(a[passenger_id_no])
Func12306.passengerPhoneList.append(a[mobile_no])
return Func12306.passengerNameList
确认好联系人之后，需要开始确认订单
def check_order(self, passengersList):
url = https://kyfw.12306.cn/otn/confirmPassenger/checkOrderInfo
passengerTicketStr = ""
oldPassengerStr = ""
for a in passengersList:
passengerTicketStr += Func12306.seatCodeList[Func12306.seatIndexOfBuy] + ",0,1,{},1,{},{},N_".format(Func12306.passengerNameList[a], Func12306.passengerIdList[a], Func12306.passengerPhoneList[a])
oldPassengerStr += "{},1,{},1_".format(Func12306.passengerNameList[a], Func12306.passengerIdList[a])
data = {
"cancel_flag": "2",
"bed_level_order_num": "000000000000000000000000000000",
"passengerTicketStr": passengerTicketStr,
"oldPassengerStr": oldPassengerStr,
"tour_flag": "dc",
"randCode": "",
"whatsSelect": "1",
"_json_att": "",
"REPEAT_SUBMIT_TOKEN": Func12306.reSubmitTk
}
response = self.session.post(url=url, data=data, headers=self.headers,cookies=Func12306.cookies, verify=False)
try:
dic = loads(response.content)
except:
return "NetWorkError"
if dic[data][submitStatus] is True:
if dic[data][ifShowPassCode] == N:
return True
if dic[data][ifShowPassCode] == Y:
return "Need Random Code"
else:
print("checkOrderFail")
return False
这里有几点需要注意：
1.在这个过程之前，12306会get一张新验证码图片，在购票紧张的时候会在购票时候弹出给你填，如果购票不紧张就不会有但是我们要get到这张图
2.判断要不要填这个验证的key在上面代码里’ifShowPassCode’ == ‘Y’就是要填，我们要做判断
这里给出新验证码的获取代码
def get_buy_image(self):
url=https://kyfw.12306.cn/otn/passcodeNew/getPassCodeNew?module=passenger&rand=randp&{}.format(random.random())
response=self.session.get(url=url,headers=self.headers,cookies=Func12306.cookies, verify=False)
path = os.path.abspath(..)
with open(path + "\\img.jpg", wb) as f:
f.write(response.content)
确认订单成功之后，我们就要开始进入购票队列
def get_queue_count(self, startStation, endStation, startDate, seatType):
url = https://kyfw.12306.cn/otn/confirmPassenger/getQueueCount
thatdaydata = datetime.datetime.strptime(startDate, "%Y-%m-%d")
train_date = "{} {} {} {} 00:00:00 GMT+0800 (中国标准时间)".format(thatdaydata.strftime(%a),
thatdaydata.strftime(%b), startDate.split(-)[2],
startDate.split(-)[0])
data = {
"train_date": train_date,
"train_no": Func12306.trainInfoNoList[Func12306.trainIndexOfBuy],
"stationTrainCode": Func12306.trainInfoNameList[Func12306.trainIndexOfBuy],
"seatType": Func12306.seatCodeList[Func12306.seatIndexOfBuy],
"fromStationTelecode": self.stationCodeDict[startStation],
"toStationTelecode": self.stationCodeDict[endStation],
"leftTicket": Func12306.leftTicketStr,
"purpose_codes": "00",
"train_location": Func12306.trainInfoLocationList[Func12306.trainIndexOfBuy],
"_json_att": "",
"REPEAT_SUBMIT_TOKEN": Func12306.reSubmitTk
}
response=self.session.post(url=url,data=data,headers=self.headers, cookies=Func12306.cookies, verify=False)
try:
dic = loads(response.content)
except:
return "NetWorkError"
if dic[status]:
print("进入队列成功")
return True
else:
print("进入队列失败")
return False
然后确认单人队列
def confirm_single_for_queue(self, seatType, passengersList, clickList = None):
url = https://kyfw.12306.cn/otn/confirmPassenger/confirmSingleForQueue
passengerTicketStr = ""
oldPassengerStr = ""
for a in passengersList:
passengerTicketStr += Func12306.seatCodeList[Func12306.seatIndexOfBuy] + ",0,1,{},1,{},{},N_".format(Func12306.passengerNameList[a], Func12306.passengerIdList[a], Func12306.passengerPhoneList[a])
oldPassengerStr += "{},1,{},1_".format(Func12306.passengerNameList[a], Func12306.passengerIdList[a])
if clickList is not None:
code = [35,35, 105,35, 175,35, 245,35, 35,105, 105,105, 175,105, 245,105]
verifyList = []
for a in clickList:
verifyList.append(code[int(a)])
codeList = ,.join(verifyList)
print(codeList)
else:
codeList =
data = {
"passengerTicketStr": passengerTicketStr,
"oldPassengerStr": oldPassengerStr,
"randCode": codeList,
"purpose_codes": "00",
"key_check_isChange": Func12306.keyIsChange,
"leftTicketStr": Func12306.leftTicketStr,
"train_location": Func12306.trainInfoLocationList[Func12306.trainIndexOfBuy],
"choose_seats": "",
"seatDetailType": "000",
"whatsSelect": "1",
"roomType": "00",
"dwAll": "N",
"_json_att": "",
"REPEAT_SUBMIT_TOKEN": Func12306.reSubmitTk
}
response=self.session.post(url=url,data=data, headers=self.headers, cookies=Func12306.cookies, verify=False)
try:
dic = loads(response.content)
except:
return "NetWorkError"
if data in dic.keys():
if dic[data][submitStatus] is True:
print("提交订单成功")
return True
elif dic[data][errMsg] == u"验证码输入错误！":
return "wrongCode"
else:
print("提交订单失败")
return False
如果以上都成功了，就会进入一个等待订单生成了过程
def wait_time(self):
url=https://kyfw.12306.cn/otn/confirmPassenger/queryOrderWaitTime?random={}&tourFlag=dc&_json_att=&REPEAT_SUBMIT_TOKEN={}.format(round(time.time()*1000),Func12306.reSubmitTk)
response=self.session.get(url=url,headers=self.headers, cookies=Func12306.cookies,verify=False)
try:
dic = loads(response.content)
except:
return "NetWorkError"
if dic[status]:
if dic[data][queryOrderWaitTimeStatus]:
if dic[data][waitTime] > 0 :
return dic[data][waitTime]
elif dic[data][waitTime] == -1:
Func12306.orderId =
Func12306.orderId = dic[data][orderId]
return dic[data][waitTime]
else:
return False
else:
return False
else:
return False
这里会有等待时间，我们获取到等待时间，然后再次发送这个请求，一直循环，直到等待时间为-1就是购票成功了 这个时候就可以开心的去12306上查询订单然后付款。
结语
和大家分享一下，有兴趣的小伙伴们可以去试试哦！ 一方面是检验一下自己的学习成果，另一方面也希望能帮你解决一下抢票的问题吧！ 不过试试归试试，还是要做2手准备哦。不要全部寄托在软件的便利上面，要经过试验才知道能否成功。
很多细节在码代码的时候遇到，但是现在总结可能就忘了说，博客写的比较粗，没有写得那么详细。 最后，希望也在研究12306的朋友可以在这里有所收获。
